11
Charge the Battery
1. Ensure the vehicle is stopped and the power switch is turned off.
2. Unlock and remove the seat (see page 10 for seat removal instructions).
3. Unplug the red battery connector (A) from the red engine connector.
4. Connect the red battery connector (A) to the battery charger connector
(B) and plug the battery charger into 120V outlet (C).
Note: Do not use the vehicle while it is plugged in.
C
