26 5 76
3 of 7
SY/MlOl
7 Connect a P-P cable to the luggage compartment switch'+'
positive terminal and route to the right-hand lamp assembly.
8 connect a B-P cable to the right-hand luggage compartment
earth point, a GW-P cable to the right-hand direction
indicator lamp and an RG-P cable to the right-hand side
lamp.
At this point you should now have seven (7) cables at the right-
hand tail lamp assembly.
Figure 1 illustrates the wiring and terminations of the addit-
ional wiring described previously.
9 Carefully drill a 7,93 mm, (0.31 in.) diameter hole along-
side the main loom grommet situa~ed near the right-hand
rear bumper mounting bracket. Suitably pr o tect the hol e !r om
corr o sion and then fit grommet UD 11866.
Take the seven core cable of the proprietary plug / socket
being fitted to the car (see figure 1) th.rough the grotmnet
previously fitted and connect the cables as given in the follow-
· ing table.
Clip the cable to the inner skin of the luggage compartment.
CABLE ROUTING SOCKET 7 CORE
.
CONNECT!ON
l .4-RY (Red/ Yellow) From Left-hand side l amp To
B -
(Bla c k)
14-GR (Green/Red) From Left-hand direction
To
y -
(Yell ow)
indicator
.
..
14-GW
(Green/White) From Right-hand direction
To
G -
(Green)
indicator
14-RG (Red/Green) From Right-hand
s· ide To
N -
(Brown)
lamp
28-P (Purple) From Positive
(+)
luggage To
u -
(Blue)
compartment lamp
28-WG (White/Green)
From stoo lame relav
(White/Purple) ··
WP
To
R -
(Red)
28-B ( Black) Prom right-hand
earth
To W -
(White)
point
Use wi th Figure
l
