26 S 76
5 of 7
SY/MlOl
10 Fit the socket mounting plate between the tow ball and
tow bracket with the bulge for the socket positioned to
the underside of the tow bracket (this prevents water
ingress into the socket).
Connect the seven (7) core cable as following table.
PLUG ANt) SOCKET
CABLE COLOUR
PIN NOMBERS
PLASTIC
METAL
l
L
y - (Yellow)
2
54G
0 -
(Blue)
3
31
w -
(White)
4
R
G -
(Green)
s
58R
N -
{Brown)
6
54
R -
(Red)
7
SSL
B -
{Black)
B FOSEBOARD AREA (See Fig. 2)
1 Lower
the fuse.board.
CIR.COIT
Left-Band direction
indicator lamps
Auxiliary
Earth
Right-Hand direction
indicator lamps
Right-Hand side/
number plate lamps
Stop Lamps
Left-Band side/
number plate lamps
2 Remove the handbrake surround trim securing screws (3) and
remove
the trim.
3 Separate the fuse.board from its support assembly.
4 Using Figure 2 as a guide fit a O'O 15249 switch ('off'
position uppermost) to the top right-hand eorner of the
front facing vertical panel. Ensure the off-set ter:::ninal
is to the left when viewed from the front of the car.
S Fit mounting bracket UA 8982/Z (required for an additional
•Lucas' flasher unit (direction indicators} 8FL type 53}
onto the top of the handbrake surround trim as Figure 2.
Secure the mounting bracket with suitable chromed headed
bolts ensuring that the bolts are sufficiently shortened to
prevent them fouling the flasher unit.
