10
• During assembly, use a small soft brush to lightly grease all gear teeth, drive shaft and axles. Both the roller bearing [10] and ball bearing race [9] are
self-lubricating and must not be greased.
• Apply only a very thin lm of Andersen Winch Grease to the pawls. Do not use any other kind of grease for this purpose. Take care to assemble with springs in
the correct orientation as shown in the diagram.
Malfunctioning pawls may lead to unexpected release of the winch force resulting in serious injury to the user and others. Check the functioning of each
pawl by depressing against the spring. The pawls should move smoothly, and automatically return to their normal position to engage within the gears. If the
pawls do not work correctly replace the springs and check again.
WORLDWIDE DISTRIBUTION & SUPPORT
www.ronstan.com
WARRANTY
www.ronstan.com/warranty
ofce@ronstan.dk
www.ronstan.com
30QT ORBIT WINCH
™
RA6302 WITH QUICKTRIM™
