30QT ORBIT WINCH
™
RA6302 WITH QUICKTRIM™
INTRODUCTION
Your Ronstan Orbit Series winch is ready to provide you with many years of easy sail
handling and reliable service.
Ronstan has been designing and manufacturing equipment for sailboats for more than 60
years. We are also known for our range of Andersen Stainless Steel Winches
®
, recognised
around the world for their exceptional nish and enduring quality. The Orbit Series draws
on the same engineering and manufacturing expertise to deliver a high-efciency winch in
lightweight aluminium. Controlled grip, smooth performance without excessive rope wear,
and a patented QuickTrim™ feature on selected models that makes ne tuning a breeze.
You have some performance options to choose from, which need to be enabled before
installing the winch, so please read this manual carefully from start to nish before proceeding.
BATCH Number
To assist with any future service inquiries, your winch has a batch number that is stamped onto
the base of the centre stem in the location shown below. The self-tailing arm and drum need to be
removed to access the batch number.
(Refer to steps 2 & 3 of the installation instructions).
30QT ORBIT WINCH
™
RA6302 Specifications
Power ratio:
1st speed: 8:1
2nd speed: 30:1
Rope dia.: 7-12mm (9/32”-1/2”)
Weight: 3.1 kg (6.8 lb)
MWL: 700 kg (1540 lb)
Batch number
