- 13 -
With your helper still holding the bed cabinet, allow
the bed to pull back into the bed cabinet. It will
recess about 3 inches into the bed cabinet.
Step 5:
At this point, the gas spring can be
removed and replaced one at a time.
Step 6:
At this point, the new gas spring can be installed.
Simply snap the new gas spring on the lower ball stud
located on the bed rail - then the upper ball stud
located on the bed vertical. BE SURE TO ORIENT
THE GAS SPRING CORRECTLY by referring to the
label on the gas spring. (MOUNT THIS END UP)
Step 7:
Repeat on the other side of the bed.
Step 9:
Replace both bed stops and screws.
Step 10:
Place the bed cabinet back against the wall and replace
the screws, MAKING SURE THE BED IS SECURELY
FASTENED TO THE WALL.
Step 11:
