Face panel and foot rail MUST be flush at this end.
The face panel MUST extend
1/4'' past edge of frame on long
sides.
Screw remaining struts to face
panel 6" apart.
Using #8 x 1-1/4" screws, screw
section marked "X" first. Keeping
end flush, screw section marked
"Y".
Making sure there is a 1/4" face
panel overhang, screw section
marked "Z".If out-of-square this
procedure will aid in racking into
square.
Step 21: Make sure face
panel and foot rail are
flush and that face panel
extends 1/4" past edge of
wood bed frame on long
sides.
- 20 -
Z Z
X Y Y X
