RootsScrub E Series (230V/50Hz)
MACHINE OPERATION
Machine Operaon:
It is the operator’s responsibility to be knowledgeable of all
potenal operang hazards and to take every reasonable
precauon to ensure safety of oneself, others, animals, and
property.
This secon of the Operator’s Manual is designed to familiarize,
instruct, and educate safe and proper machine use to the
operator. The operator must be familiar with the machine
operaon and all associated safety pracces before operang.
Proper operaon of the machine, as detailed in this manual, will
help ensure years of safe and sasfactory use of the machine.
READ, UNDERSTAND, and FOLLOW the safety messages. Serious
injury or death may occur unless care is taken to follow the
warnings and instrucons stated in the safety messages. Always
use good common sense to avoid hazards.
Only qualified people are allowed to operate the machine. A
qualified operator has to read and understand the owner’s
manual and should comply with its procedures. If any part of the
operaon and safe use of this equipment is not completely
understood, consult an authorized dealer for a complete
explanaon.
If the operator cannot read the manuals for himself or does not
completely understand the operaon of the equipment, it is the
responsibility of the supervisor to read and explain the manuals,
safety pracces, and operang instrucons to the operator.
Operator Requirements:
a. Train the employee to operate the machine in a safe way.
b. Permit only qualified personnel to operate and service the
machine.
c. Instruct all operators to maintain the shields and guards in its
proper working condion at all mes.
d. Ensure that the operators use approved Personal Protecve
Equipment at all mes or whenever required.
e. Forbid the operators to carry addional people on the truck or
the machine.
f. Ensure that nobody including the operator modifies or alters
the machine or any of its funcon, doing so may cause fatal
injury or death or it may damage the machine itself.
g. Ensure that children do not operate the machine.
Employer Responsibilies:
Before Starng the Machine:
Before operang the machine, ensure that the
equipment is working properly and that you are
prepared for sweeping operaons by checking the
Pre-operave checklist and tesng the machine funcons.
Owner's personnel are not allowed to unpack the
machine.
After Unpacking
Verify the machine and accessories with the invoice copy. Check
the machine for any transit damage, if found contact the
branch/dealer immediately.
Identification of Main Parts
3b
3c
4a
4b
450
5
2
6
3a
1
810
7
9
1. Fresh water tank
2. Dirty water tank
3. Brush head
a) Disc type
b) Cylindrical type
c) Twin Disc type
4. Squeegee
a) Straight
b) Parabolic
5. Handle
6. Fresh water fill port
7. Control panel
8. Fresh water level indicator
9. Squeegee control handle
10. Pedal for raise/lower brush head
