Smart-Vision
TM
4.3" Mirror/Monitor
Combo Backup Camera System
Rosco Vision Systems introduces a revolutionary new
backup camera system for small to medium vehicles.
Smart-Vision
TM
utilizes an interior rearview mirror to
display a 4.3" LCD monitor when the vehicle shifts into
reverse. This monitor allows the driver to see behind
the vehicle for added convenience and safety while in
reverse. At other times, the full area of the mirror-glass
is reective just like a standard interior mirror.
Rosco’s rear view license plate camera gives the driver
a 180 degree wide and clear views of what's behind
the vehicle, allowing the driver to back up safely in all
weather conditions. The convenient and simple design
afxes over your existing rear license plate, permitting
the camera to be installed on the existing license plate
holes of the vehicle. Perfect for Mini Vans, SUV's,
Sedans, pick-up trucks and more.
General Technical Specications:
Power Supply: 12VDC
Power Consumption: ~3 Watt
Current Draw: ~250 mA
Video Input: 1 Vp-p@75 impedance
Monitor Dimensions: 11"W x 3"H x 1.5"D
Installation Tools:
C O N T E N T S
How To Operate
Display .............. 4
Color Camera ... 7
Wiring
Diagram ......... 5-6
Rearview Mirror
Installation ....... 8
Camera
Installation ....... 9
Testing &
Maintenance .. 10
1. Wire Tester 4. Wire Stripper 7. Drill
2. Phillips Screwdriver 5. Pencil 8. Tape
3. Tape Measure 6. Drill Bits 9. Wire Ties
(Not Shown)
1.
2.
3.
4.
5.
7.
8.
6.
A Century of Automotive Safety
