Rosewill N150 User Manual

For more conguration methods of WPS, please refer to the User Guide on the Resource CD.
Appendix: Connect to Wireless Router by WPS
If your wireless Router features the WPS/QSS function, you can also set up a wireless connection in this way.
Connect to Network
3
(You can skip to Appendix: Connect to Wireless Router by WPS to quickly connect to a network if your Router or Access Point features WPS/QSS function.)
2
Click Network in the tools section to display a list of available
wireless networks. Highlight the target network name (e.g.
Network1) and then click Connect to build a connection.
Launch the conguration utility and click WPS in the
tools section. Select Push the button on my access
point or wireless router and then click Connect.
2 3
Wait for the connection process to complete.
The following screen indicates successful connectivity.
Click OK to nish the WPS connection.
The following screen indicates successful connectivity.
Click Close to enjoy the Internet.
4
1
After installation, the conguration page will pop up
on your desktop.
1
Push the WPS/RESET button on the Router.
(Here we use a router as an example.)
3
Method One:
Input the wireless password into the Security Key eld and
then click OK to continue.
If the network is unsecured, you will directly connect to it.
If it is secured (with WPA/WPA2-PSK), there are two ways to
connect to it.
To view more information about the network connected,
click Status in the tools section.
5
Method Two:
Without entering a key, push the WPS/QSS button on your
Router as hinted “You can also connect by pushing the button
on the router”. Then click OK to continue.
The icon will appear on your desktop. Double-clicking
on the icon can start the utility.
Here we only choose a wireless network with the security
type of WPA/WPA2-Personal as an example to elaborate
the following steps.
If you want to know more about the connection to a
wireless network with the security type of
WPA/WPA2-Enterprise, please refer to the User Guide on
the resource CD included.
Thank you for purchasing a High-Quality Rosewill Product.
To download the latest software and user guide, please visit
Rosewill ocial website at www.rosewill.com
If you have any question while using our products, feel free to
contact us.
Support Phone Number: 800-575-9885
Support Email: techsupport@rosewill.com
