4
SPECTRA D100
Gaming Case
Installation Guide
1. Open the Unit
1-1. Remove the thumb screws and take off panels R and L (Figure 1).
1
2
2. Install Power Supply
2-1.
Seat the power supply unit (PSU) at the bottom-rear of the case and secure with Screw-A (Figure 2).
