Rosewill ZIRCON I User Manual

2 3
INSTALLATION GUIDE
FRONT I/O
1
2. Install Power Supply
2-1. Set the power supply unit (PSU) at the bottom-rear of the case and secure with Screw-A
(Figure 2).
1. Open the Unit
1-1. Remove the thumb screws and take off panel R and L (Figure 1).
2
Accessory Box
FRONT I/O CABLE PINOUT
x8 x18 x8
x1
Screw-A
(6-32 x 6 mm)
Screw-B
(M3 x 5 mm)
Screw-C
(8mm)
VGA Holder
PSU
Add-on Card
Motherboard
2.5” HDD/SSD
3.5” HDD
Vertical VGA
Installation
x1
x1
x5
Thumb screw
Speaker
Cable Tie
VGA Holder
Motherboard
Cable
Management
x9
Standoff
Motherboard
x2
Slot Cover
PCI-e Slot
Speaker
MIC
USB 3.0
Reset
LED
Power
USB 2.0
USB 3.0 CONNECTOR USB 2.0 CONNECTOR HD Audio CONNECTOR
