Technical Specifications
AC-Q4x Series Installation and Programming Manual 13
AC-Q41HB AC-Q42HB
AC-
Q41SB
AC-
Q41HP
AC-
Q42SB
AC-
Q42HP
AC-Q44
Proximity
Modulation
N/A ASK at 125
kHz
N/A ASK at 125 kHz
Proximity Card
Compatibility
N/A 26-Bit EM
cards
N/A 26-Bit EM cards
LED Indicators
Two tri-colored LED (Mode and Door)
Operating Temp.
Range
-20ºC to 60ºC (-4ºF to 140ºF)
Outdoor Usage
Water resistant, meets IP54 Weather resistant, epoxy-potted, meets IP65
Size (H x W x T)
120 x 76 x 27 mm
(4.7 x 3.0 x 1.1 in.)
120 x 76 x 22 mm (4.7 x 3.0 x 0.9 in.)
Weight
440 g (1.0 lb) 521 g (1.2 lb)
* Measured using a Rosslare proximity card or equivalent. Range also depends on electrical environment and proximity
to metal.
