52 AC-Q4x Series Installation and Programming Manual
The left LED flashes green.
4. Enter the assignment digit for the current user slot:
 1 activates the Lock Strike relay only default
 2 activates the Auxiliary relay only
 3 activates the Lock Strike and Auxiliary relays
If the assignment code is valid, the left LED stops flashing.
The controller is now waiting for another slot number.
5. Do one of the following:
 Press # to move to the next available user slot number.
 Enter another 3-digit user slot number.
If you do not wish to continue enrolling codes, press # twice and
the controller returns to Normal mode.
5.15.2 Relay Code Assignment using Search Method
To assign the relay code using Search method:
1. Enter Programming mode.
2. Press 9 to enter Menu 9.
The left LED turns green and the right LED
turns orange.
3. Enter 000 for user slot access.
The right LED flashes orange.
Green Orange
Green Orange
Green
Green
Orange
