Page 5
08/01
Operating Humidity:
Dimensions:
Weight:
0 to 95% (Non-Condensing)
Suitable for outdoor use. (IP 44)
4.72" (120mm) L x 3" (76mm) W x 1" (27mm) D
0.9 lbs (410g)
Built-In Keypad for PIN code entry
Programmable Keypad Transmission Format
Built in Case and Back Tamper
Tamper Output & LED Control Input
Programmable Facility Code
Two Tri-Colored LED’s
Internal Buzzer provides audible interface feedback.
Comes with mounting template for easier installation.
Comes with Installation Kit that includes a security screw
and a security screw tool.
Mechanical Characteristics
!
!
!
!
!
!
!
!
!
Key Features
Here are some of the AY-Q54's key features:
AY-Q54
06/01
Technical Specification
Electrical Characteristics
Environmental Characteristics
Operating Voltage Range:
Maximum Input Current:
Built-In Keypad Reader
LED Control Input
Tamper Output
Operating Temperature:
5 to 16V DC From a Regulated Power Supply
(Linear type recommended)
Standby: 20mA Not including attached devices
Max: 60mA Not including attached devices
Transmission Formats:
1) Single Key, 6-Bit Wiegand (Rosslare Format)
2) Single Key, 6-Bit Wiegand with Nibble and Parity Bits
3) Single Key, 8-Bit Wiegand, Nibbles Complemented
4) 4 Keys Binary + Facility Code, 26-Bit Wiegand
5) 1 to 5 Keys + Facility Code, 26-Bit Wiegand
6) 6 Keys BCD and Parity Bits, 26-Bit Wiegand
7) Single Key, 3x4 Matrix Keypad
8) 1 to 8 Keys BCD, Clock & Data
Dry Contact, N.O.
Open Collector, active low, maximum sink current is 32mA
-25°F to 145°F (-31°C to 63°C)
Page 4
AY-Q54
To Next Page
