Rosslare AY-Q54 User Manual

Selecting Keypad Transmission Format
The AY-Q54 has eight different keypad transmission formats to
select from. Follow the steps below to select the appropriate keypad
transmission format that you wish to use.
Enter Programming Mode
Press to enter
The Transmit LED will turn red
Enter the appropriate option number
for the keypad transmission format
that you wish to select.
If an incorrect option number is entered the reader will return to
Transmit Mode and the keypad transmission format will remain
unchanged
Look on the next page for more information on the keypad
transmission formats.
System returns to Transmit Mode
You will hear one beep
The Program LED will turn off
The Transmit LED will turn red
- Only one keypad transmission format can be active at
any one time.
- When using the keypad transmission format “1 to 8 keys
BCD, Clock & Data” (Option 8) an additional input is
required to specify the number of keys in the PIN code.
1)
2) "1" Menu 1
3)
4)
Note:
!
!
!
!
Page 11
06/01
AY-Q54
Transmit Program
GREEN
Page 10
06/01
Entering Programming Mode
Exiting Programming Mode
1) "#"
2)
Note:
1)
"#"
2)
3)
Press the key for 2 seconds.
Transmit LED will turn off
Program LED will turn red
Enter your 4-digit Programming
Code.
If the Programming Code
is valid the door LED will turn
green and the AY-Q54 will be in
Programming Mode.
- The factory default Programming Code is 1234
- If a Programming Code is not entered within 30
seconds, the AY-Q54 will return to Transmit Mode.
To exit the Programming Mode at any time:
Press the key.
You will hear a beep
The Program LED will be off
The Transmit LED will turn green
This indicates that the AY-Q54 has returned to Transmit Mode.
Wrong entries may reset the read
1to8
to Transmit Mode.
While in Programming Mode if no key is pressed for 30 seconds
the AY-Q54 will exit Programming Mode and return to Transmit
Mode.
!
!
!
!
!
AY-Q54
Transmit Program
Transmit Program
GREEN
RED
12
3
4
Transmit Program
GREEN
1
?
Transmit Program
GREENRED
Transmit Program
RED
