Programming the AY-Q54
Programming the AY-Q54 is done solely via the unit's keypad driven
Programming Menu System. To reach the Programming Menu
System the AY-Q54 must first be placed into Programming Mode.
See "Entering Programming Mode" on the next page for more
information.
During the AY-Q54's manufacturing process certain codes and
settings are pre-programmed. These settings are the called the
"Default Factory Settings".
The table below shows the names of all the AY-Q54 Menus.
1) Single Key, 6-Bit Wiegand (Rosslare Format)
2) Single Key, 6-Bit Wiegand with Nibble + Parity Bits
3) Single Key, 8-Bit Wiegand, Nibbles Complemented
4) 4 Keys Binary + Facility Code, 26-Bit Wiegand
5) 1 to 5 Keys + Facility Code, 26-Bit Wiegand
6) 6 Keys BCD and Parity Bits, 26-Bit Wiegand
7) Single Key, 3x4 Matrix Keypad
8) 1 to 8 Keys BCD, Clock & Data Single Key,
Programming Menu
Selecting Keypad Transmission Format 1
Changing the Programming Code 3
Changing the Facility Code 4
Return to Factory Default Settings 0
Page 09
06/01
AY-Q54
Menu Description
Menu
Number
Transmit Mode
When the AY-Q54 is in Transmit Mode, it is ready to receive data
from an entered PIN code.
When the reader is in Transmit
Mode, the Transmit LED is red
and the Program LED is off
When a Keyboard entry is being transmitted, the Transmit LED
will flash green.
Keyboard data can be sent via one of eight different Keypad
Transmission Formats. (Refer to page 13 for more information on
Selecting Keypad Transmission Formats”)
Page 08
06/01
AY-Q54
Transmit Program
RED
To Next Page
