Controller Operation
44 AYC-Ex5/T65 Series Installation and Programming Manual
3 Normal/Secure
switch
Tamper event N.C. 01 to 99 Aux.
relay release time
4 Normal/Secure
switch
Direct shunt N.O. 01 to 99 Shunt
time
5 Door Monitor Shunt N.C. 01 to 99
Maximum shunt
time
6 Door Monitor Forced door N.C. 01 to 99 Forced
delay
7 Door Monitor Door ajar N.C. 01 to 99 Ajar
delay
8 LED control –
Valid code N.O. 01 to 99 Aux.
9 LED control – Red Valid code N.O. 01 to 99 Aux.
relay release time
The following subsections describe each Auxiliary mode.
4.9.9.1 Auxiliary Mode 0
Auxiliary input function: Activates the auxiliary output
Auxiliary output activated by: Valid user code, Auxiliary code, and
Auxiliary input
For example, in Auxiliary Mode 0, the controller can function as a
two-door controller. The auxiliary relay is to be attached to the lock
on the second door. The auxiliary setting defines the door open
time for the second door. The auxiliary input is to be attached to the
REX pushbutton for the second door. The Door Monitor input
feature for the second door is not enabled when using this mode.
4.9.9.2 Auxiliary Mode 1
Auxiliary input function: Toggles Normal/Secure modes
Auxiliary output activated by: Valid user code, Auxiliary code
For example, in Auxiliary Mode 1, the controller can function as a
two-door controller. The auxiliary relay is to be attached to the lock
