Rotel C8 - Front Panel Controls and Indicators; Power Button; Zone 1-4 Controls; Function Buttons

3
English
ZONE 1 ZONE 2 ZONE 3 ZONE 4
ZONE 1
ZONE 2
ZONE 3 ZONE 4
RP-613A
BRIDGED ZONE 1&2 BRIDGED ZONE 3&4
ENTER
MENU
BACK
FUNCTION
C8
1 2
8
9 = q
3 4
75
-0
Figure 1-1: Controls and Connections
Commandes et branchements
Bedienelemente und Anschlüsse
Controles y Conexiones
Bedieningselementen en aansluitingen
Controlli e connessioni
Kontroller och kontakter
Органы управления и разъемы
1
: Power Button
Activate the unit or put it into standby mode
2
: ZONE 1 - 4
Congure the volume, source, bass treble and balance for Zone
1 to Zone 4 respectively.
3
: Display
4
: Function Buttons
Navigating and ENTER Buttons
MENU Button
BACK Button
