Installation - Technical Detail
Model Thermostat Basicline T 230 V
Type Electronic programmable room thermostat, digital room
thermostat designed for 230 V AC applications
Programming Modes User selectable for 5/2, ALL and Individual day options
Program Number 1-6 Selectable
Modes Party, Vacation, Program and Frost
NSB 230 V Output
Override Permanent and temporary
Frost Protection 5 ºC Adjustable
Power Source 230 V AC 50Hz
Rating 230 V AC/max. 3A
Temperature Scale 5 to 35 ºC, tolerance 0.5 ºC
Heat/Cool Local changeover
Sensor Air or oor protection.
Device Parameters See page 90 for full list of functions
Operating Temperature 0 to 50 ºC
Storage Temperature -20 to 60 ºC
Installer Manual 93
INSTALLATION
