Installation – Thermostat Mounting
1
3
2
60mm
Wall Mounting
For wall mounting, mark and mount the
rear case to the wall. The room
thermostat is suitable for wall boxes with
a centre hole distance of : 60 mm
Gently remove front housing.
54 Installer Manual
Gently remove front housing.
Only for ush
mounting boxes
with horizontal
xing holes.
