Roth Basicline T - Page 8

L N
L N
S2
S1
NSB
SL
L
N
56 Installer Manual
S2
S1
NSB
SL
L
N
Sensor Terminal (optional)
Sensor Terminal (optional)
Night set back output
Load (Thermal Actuators)
Live 230 V AC 50Hz
Neutral
Wiring Centre
Thermal
Actuator
Optional
Sensor
Installation – Terminal Connections
NSB for other
thermostats
Output
