7.4 Two plane dynamic balance using surface A and B shown on Figure 2-7. Trim
balance to ½ of the out of balance by drilling as indicated on Figure 2-7. Balance to
within the following limits at 970-1000 RPM: .15 in. oz. max. per plane. Caution:
Sufficient guarding should be used when balancing the rotating assembly.
7.5 Drain rotor assembly.
7.6 Remove rotor cover (4) to prepare for next assembly step. See Section 4.3.
8. PARTS
8.1. SPARE PARTS
Table 8-1: Minimum Recommended Spare Parts List
ITEM PART NO. QTY.
Bearing Kit
Direct Drive
Belt Drive
0665807-01
0665807-02
1
Seal Kit – Single Seal Pusher - Nitrile
Non-Abrasive Service 2-7/8” Carbon vs.
TC
0664975
1
Seal Kit – Single – Seal Pusher - Viton
Non-Abrasive Service 2-7/8” Carbon vs.
TC
0664975-01
Seal Kit – Double Seal – Pusher
Non-Abrasive Service 3-1/2” Carbon vs.
TC
Abrasive Service 3-1/2” TC vs. TC
0665290
0665290-02
Seal Kit – Double Seal – Bellows
Non-Abrasive Service 3-1/2” Carbon vs.
TC
0665291
Pick-up Tube Replacement Kit 0665213 1
