11
Spare Part No. Spare Part No.
Product
No.
Position
Description Qty
Product
No.
Position
Description Qty
42595 001 Swing arm 1 42595 035 Chain drive 1
42595 002
Grinding disk enclosure
body
1 42595 036 Counter nut 2
42595 003 Lateral guard 1 42595 037 Limiting spring 1
42595 004 Switch enclosure 1 42595 038 Spring 1
42595 005 Enclosure 1 42595 039 Threaded pin 1
42595 006 Limiter 1 42595 040 Case 1
42595 007 Grinding disk 3 42595 041 Plastic ring 1
42595 008 Flange 1 42595 042 Hand wheel 1
42595 009 Flange 1 42595 043 Scale 1
42595 010 Set screw 1 42595 044 Scale 1
42595 011 Counter-nut 1 42595 045 Scale 1
42595 013 Holder 1 42595 046 Screw M5X10 7
42595 014 Coupling 1 42595 047 Screw M5X12 2
42595 015 Switch 1 42595 048 Screw M5X12 3
42595 016 Motor 1 42595 049 Screw M6X25 2
42595 017 Joint 1 42595 050 Screw M6X30 2
42595 018 Axis 1 42595 051 Screw M8X45 1
42595 019 Clamping wheel 1 42595 052 Screw M10X40 1
42595 020 Spring 1 42595 053 Nut M6 6
42595 021 Case 2 42595 054 Nut M8 2
42595 022 Base plate 1 42595 055 Washer ¢5X14 2
42595 023 Swing support 1 42595 056 Washer ¢8 1
42595 024 Clamping rod 1 42595 057 Wide washer ¢10 1
42595 025 Set screw 1 42595 058 Plastic ring ¢12 1
42595 026 Wide washer 1 42595 059 Cone ¢5 2
42595 027 Spring 1 42595 060 Pull-off stone 1
42595 028 Small thrust spring 2 42595 061 Sharpening block 1
42595 029 Axial bolt 1 42595 062 Wrench M5 1
42595 030 Clamping lever rod 1 42595 063 Wrench M6 1
42595 031 Ball holder 1 42595 064
Lamp 120V E12
15W
1
42595 032A Chain support 1 42595 065 Condenser 1
42595 032B Chain support 1 42595 066 Cable 1
42595 033 Case 2 42595 067
Column action
protection
1
42595 034 Connecting catch driver 1
For replacement parts and technical questions, please call 1-800-222-5381.
