Thank you very much for choosing a Roughneck product! For future reference, please
complete the owner’s record below:
Model: ______42595_________ Purchase Date: _______________
Save the receipt, warranty and these instructions. It is important that you read the entire
manual to become familiar with this product before you begin using it.
This sharpener is designed for certain applications only. The distributor cannot be
responsible for issues arising from modification. We strongly recommend this sharpener
not be modified and/or used for any application other than that for which it was designed.
If you have any questions relative to a particular application, DO NOT use the sharpener
until you have first contacted the distributor to determine if it can or should be performed
on the product.
For technical questions please call 1-800-222-5381.
GENERAL SAFETY RULES
WARNING: Read and understand all instructions. Failure to follow all instructions
listed below may result in serious injury.
CAUTION: Do not allow persons to operate or assemble this sharpener until
they have read this manual and have developed a thorough understanding of how the
sharpener works.
WARNING: The warnings, cautions, and instructions discussed in this
instruction manual cannot cover all possible conditions or situations that could occur.
It must be understood by the operator that common sense and caution are factors that cannot
be built into this product, but must be supplied by the operator.
List of Contents
Description Page
1. Parts Description…………………………………………………………………………….3
2.
T
e
chnical Data……………………………………………………………………….………3
3. General Safety Precautions………………………………………………………………..3
4. Assembly……………………………………………………………………………………..5
5.
Grindi
ng Disk Check………………………………………………………………………...6
6. Grinding Disk Assembly………………………………………………………………….....7
7.
Clamping Screw Set Up…………………………………………………………………….7
8.
Grindi
ng………………………………………………………………………………………8
9. Grinding Depth Delimiter…………………………………………………………………
…9
