Roughneck 42595 - Parts Description; Technical Data; General Safety Precautions

2
10. Dimensions………………………………………………………………………………….10
11. Assembly Drawing………………………………………………………………………….11
12. List of Spare Parts………………………………………………………………………….1
2
1.
Pa
rts Description
1. Handle
2. Grinding disc lateral guard
3. Set screw for depth
4. Cutting edge angle setup wheel
5.
B
a
se
6. Screw clamp cradle
7. Cutting angle setting wheel
8.
Scale
9. Clamp
i
ng lever
10.
Mean
distance set scr
ew
11. Guide position set screw
12.
Sc
rew clamp
13.
Guide p
o
sition set screw1
14. Set screw
15.
Grin
ding disc
16.
Grinding disc protective enclosure
2. Technical Data
Supp
ly voltage: 110Volt/60Hz
Motor input power: 2.1Amps
Maximum speed: 3580 RPM
Noise level: ±70dB(A)
Weight: 17.2lbs.
Product No.: 42595
3. General S
afety Precautions
Re
ad the instruction manual carefully before using this sharpener. If you have any question
regarding the connection and operation of the machine, see the manufacturer’s service
department.
• Protect the machine from moisture, rain and dust.
• Use the machine only for the scope of work for which it has been designed.
