Intended Use
The Roughneck Digital Oil Meter is ideal for measuring oil in the automotive industry. The high
pressure, positive displacement meter is suitable for both in-line and end of line applications.
Packaging Contents
• Digital Oil Meter
• Owner’s Manual
Technical Specifications
Description
Specification
Meter Type
Digital
Mechanism
Oval gear
Inlet / Outlet Position
In-Line
Inlet / Outlet
1/2” NPT (F)
Flow Rate
0.3 to 8 GPM
Accuracy
+/- 0.5 %
Repeatability
0.20%
Max. Working Pressure
1000 PSI (70 BAR)
Pressure Loss
10 PSI (0.7 BAR)
Working Temperature
range
6.8° F to 131° F
Max. Resettable Batch
Total
99999.9 units
Max. Non-Resettable
Totalizer
999999 units
Least Count / Resolution
0.0010 unit
Filter/ Screen Included
No
Max. Viscosity of Media
SAE 140 / 1000 CP
Option to Recalibrate by
User
Yes
Protective Shroud on
Meter
Yes
Display Output
User Selectable for 0.1, 0.01, 0.001 units
Water Resistance
IP65
Battery
3V Lithium Ion
Wetted Components
Aluminum, Steel, Nitrile Rubber, & Acetal
Recommended Use
Oils with Viscosity up to SAE 140, Diesel, Kerosene and Engine
Coolants (RTU)
Important Safety Information
⚠WARNING
• Read and understand all instructions. Failure to follow all instructions may result in serious injury
or property damage.
• The warnings, cautions, and instructions in this manual cannot cover all possible conditions or
situations that could occur. Exercise common sense and caution when using this tool. Always be
