Fuses
159
RIGHT HAND SEAT FUSE BOX
Fuse number Rating (AMPS) Circuit protected
1 10A Instrument pack, clock, radio, centre console
2 30A RH rear window, seat heaters
3 5A Automatic gearbox ECU
4 30A Transfer box ECU
5 - Not used
6 10A Rear view mirror dip, sun visor illumination
7 10A Auto gearbox ECU, transfer box ECU
8 30A Car phone, aerial amplifier, cigar lighter, radio,
heating, ventilation and air-conditioning
9 20A Front audio system amplifiers, front doors
10 30A RH seat
11 - No fuse installed (insert fuse - 5 amp or more -
to select transfer neutral)
12 30A Heated rear screen and LH rear window
13 20A Shift interlock solenoid, key inhibit solenoid,
sunroof
14 20A Rear central door locking, fuel flap solenoid,
trailer socket, tailgate central door locking
15 20A Courtesy lights, handset receiver, loadspace
light, rear wiper, sub-woofer, rear audio system
amplifiers
16 - Not used
17 10A Brake switch
18 - Not used
19 - Not used
20 30A LH seat
21 - Not used
22 30A LH and RH front doors (windows only)
This fuse box contains five spare fuses, one each of 5A, 10A, 20A and two 30A.
