Bulb replacement
165
Front fog lights
Twist the plastic cap at rear of the light unit to
release, then squeeze the spring clip and
withdraw the bulb holder. Disconnect the bulb
holder electrical lead connector and then
remove.
Replace the bulb and bulb holder as one
assembly.
Stop, direction indicator & tail lights
NOTE: If your vehicle is fitted with a CD
autochanger, to access the left hand cluster, it
will be necessary to remove the rear trim
panel by releasing the four fasteners.
Press the latch to remove the access panel,
then squeeze the two clips (one on each side
of the light unit) and withdraw the unit
through the access aperture. Press and twist
the appropriate bulb to remove.
Top - direction indicator
Centre - tail light
Bottom - stop light.
