11
User
Manual
The maximum loads listed here below take into account the 10-fold safety!
1. Rigging by integrated 1/4 turn Camlocks on top- or rear side
2. Rigging by Yoke with multiple mounting points
User
Manual
Max. Tension Load: 90kg
Max. Torsion Load: 18.703 Nmm
Max. Tension Load: 90kg
Max. Torsion Load: 14.201 Nmm
a. With 1x Mounting Clamp
Max. Tension Load: 40kg
Max. Torsion Load: 4.414 Nmm
c. With 1x Omega Bracket
Max. Tension Load: 51kg
Max. Torsion Load: 4.768 Nmm
b. With 2x Mounting Clamp
Max. Tension Load: 77kg
Max. Torsion Load: 7.308 Nmm
d. With 2x Omega Bracket
Max. Tension Load: 90kg
Max. Torsion Load: 5.943 Nmm
