27
User
Manual
Main
Menu
Menu
level 2
Menu
level 3
Menu
level 4
Menu
level 5
Menu
level 6
Remark
Settings
LED Mode
Illumination
Normal output for constant
illumination
Boost
Boost for temporarily hig
-
hest output for blinder and
strobe effects
USB Update
Yes
Run rmware update via
USB port / keeps the current
DMX Address
No
Do not run rmware update
via USB port
Factory /
User Reset
Factory Reset
Are you sure to reset?
Conrm by pressing ENTER,
cancel with ESC
Select your User
Reset defaults
Note: Factory Reset by Menu
sets DMX address back to
1 and DMX mode back to
default mode
Factory Reset by DMX / RDM
keeps current DMX address
and DMX mode
User Reset
Are you sure to reset?
Conrm by pressing ENTER,
cancel with ESC
Restores all User Reset
according to the User Preset
List. DMX address restore
to Factory default. Once
User Reset is activated a
xture self test will start
while dimming in and out
every single LED and eye
and fan. Self Test is not
available while activating
User Rest by DMX Settings.
Use r Reset List
15CH Simple, 31CH Easy,
64CH Standard, 112CH
Pure, 209CH Pure Mode
168 CH Full Access, 265CH
Full Access Extended
Select your User
Reset defaults
Color Settings
<Factory Calibration, RAW>
Protocol
<
DMX
/Art-Net/sACN/
Display Flip <on/off>
Backlight <on/off>
Auto Lock <on/off>
Startup Mode
<DMX, Art-Net, sACN,
Auto,Color Macro,
Q u i c k C o l o r , Tu n a b l e -
White, User Color >
DMX Fail
<
Hold
/Blackout/Emergency>
Dimmer Curve
<Linear, Exponential,
Logarithmic, S-Curve>
Dimmer Response
<LED, Medium, Halogen>
Color Calibration
<Full Calibration/
CCT Calibration>
To Next Page
