6
3.Rotate the rebound adjuster as indicated on the sticker to adjust
4.Note: A minimum amount of fork movement (0~15mm) could
Tiny Remote Lockout Assembly
The TRL lever is the smallest, lightest, multi-setting remote lever RST has ever offered.
The interchangeable release button allows the rider to choose the optimum position of
the TRL lever on either side of the handle bar.
Instruction for the TRL assembly:
1. Choose the release lever position once you found
the optimum side on the handle bar for the lever
2. Unscrew the release button and take out the spring,
alloy washer and xing bolt
3. Put in the bolt first, then the alloy washer and the
spring before tightening the release button
4. Tighten the open clamp with 2.5Nm maximum
the rebound faster or slower.
appear when the fork is in the lockout position. This is normal in
the design of the fork.
Rebound adjustment
Hydraulic damping system with external rebound adjustment.
1. Rotate the rebound adjuster clockwise to increase the rebound
damping and turn it counterclockwise to decrease the rebound
damping.
2. Turn the adjuster knob then test the fork to make sure the rebound
damping can meet your requirement. If not, try another 1/2 turn.
Air spring system
RST air spring system provides the positive air chamber and negative coil spring to
make the fork lightweight and allows for easy air pressure set up.
The Air system is a built-in type and it needs to be adjusted according
to the different needs and desires of different riders. Consult the table
below to select the air pressure that is the best for you.
