Audio Matrix Switch
AD-16x
20
WIRING FOR REMOTE AUDIO SOURCES
RSP-1 Remote Source wall plates installed for audio sources are wired to the
AD-16x remote source inputs.
Use standard Cat-5 cable between the RSP-1 Remote Source Plate and the RJ-
45 jacks on the rear of the AD-16x. The output of the remote audio source can
be wired to either the stereo RCA jacks or the 3.5mm mini stereo jack on the
RSP-1.
NOTE: The AD-16x can accommodate a total of 500 feet of Cat-5 cable for
each zone. For the most reliable operation, it is best that no single run of Cat-5
exceeds 250 feet. The wiring scheme for the Cat-5 cable is standard EIA/TIA
568B.
CONTROLLING REMOTE AUDIO SOURCES
The Remote Source IR Inputs allow infrared control to be passed through the
AD-16x to an audio source via the Cat-5 cable wired to the RSP-1 Remote
Source wall plate. The IR output of a control processor is wired to the remote
source 3.5mm IR inputs on the rear of the AD-16x. Each remote source has
an IR input for independent control. The “All” input on the AD-16x provides IR
control to all remote sources when discrete control is not required.
NOTE: When using the “All” input on the AD-16x, the control processor infrared
high output port must be used.
CHAPTER 3 | INSTALLATION AND OPERATION
