It’s Under Control
®
CHAPTER 4 | SPECIFICATIONS
Power Supply 100VAC ~ 240VAC, 50~60Hz Switching Power
Supply, 20W
Mounting Rack mount or free standing
Dimensions
(W x H x D)
16.9” (430mm) x 5.3” (133mm) x 14.5” (369mm)
Weight 14.5lb (6.6kg)
Operational
Temperature
32°F - 104°F (0°C – 40°C)
Humidity 5% to 95% Non-Condensing
Heat Output 68 BTU/hr
Warranty One Year (Parts & Labor)
All specications subject to change without notice.
GENERAL
Output Zones Sixteen zones of stereo L/R, 16 RCA jack pairs
(switchable between xed or variable)
Audio Source Inputs
(Local)
Sixteen, 16 RCA jack pairs
Audio Source Inputs
(Remote)
Eight, RJ-45 jacks
Loop Outputs Sixteen, 16 RCA jack pairs
Control Input
(CTRL IN)
One, 3.5mm jack, compatible with industry
standard IR repeaters and receivers
Control Output
(CTRL OUT)
One, 3.5mm jack, compatible with industry
standard IR repeaters and receivers
Remote Source IR
Inputs
Nine, Eight discrete, One universal (All), 3.5mm
jacks
Mute Input One, 3.5mm jack
Phone Input Sensitivity: AC25V-AC100V 20Hz
Doorbell Sensitivity: AC/DC 3-12VDC
Trigger Output
(Status Jack)
One, 12VDC, 15mA max
+12VDC
Voltage Output
One, 12VDC, 500mA max
Serial (RS-232) Port One, Bi-directional DB-9
Ethernet Port
One, 10/100Base-T, RJ45 Connection
Unit ID Numbers 1-8, Set using 3 switches
CONTROL & CONNECTIONS
