11
It’s Under Control
®
CHAPTER 2 | INTRODUCTION
FEATURES
The RK3-V provides superior quality and reliability as well as these features:
Stylish low-prole faceplate bezel available in many colors and styles.
Available with multiple faceplate and button color options.
Full VGA resolution LCD to display custom buttons, text and graphics.
Integrated high-resolution touchscreen.
Integrated 10/100Base-T Ethernet port with Power-over-Ethernet.
Plasma friendly infrared receiver for command pass-through.
IR output port drives up to 1,000 feet of wire.
Two power status input ports.
Powerful 32-bit, 400MHz XScale processor.
512MByte of Flash Memory.
Integrated mounting wings for easy installation.
Nine assignable/programmable keys.
Completely customizable and programmable.
Non-volatile Flash Memory stores your program even when power is
lost.
Field upgradable rmware.
USB and Ethernet programming.
IMPORTANT NOTES
Please read these important notes about the RK3-V:
The RK3-V should be placed in an area where it is around normal room
temperature (between 60° F to 90° F). If the temperature is too hot,
the display appears dim. If the temperature is too cold, the display
appears dark and may respond slowly.
Avoid installing the RK3-V in a location where it can come in contact
with direct sunlight.
Do not install the RK3-V directly adjacent to thermostats. Heat
generated by the RK3-V may effect temperature measurement.
Do not use sharp objects on the touchscreen. It is designed to operate
with a touch of your nger.
Do not let the RK3-V get wet. It should not be handled with wet hands
or placed in an area where it could get wet.
Do not subject the RK3-V to smoke, dust, or vibrations. The display
may be damaged from excessive shock or vibration.
Only use the power supply that is specied for the RK3-V. Using the
wrong type of power supply may result in damage.
Do not disassemble the unit. Service of the RK3-V should be performed
by authorized personnel only.
