RTI XP-6 - XP-6 Diagram

Remote Control Processor
XP-6
12
CHAPTER 2 | FEATURES
IR Output Adjustment Controls
Ethernet
RS-232
USB
Power
Supply
RTI COM Port
Expansion Port
MPIO Ports
(IR, CM-232, VPS-1/SPS-1)
Power/IR
DC Trigger
DC Sense
Relays
Status Light
Reset Button
