21
It’s Under Control
®
CHAPTER 4 | SPECIFICATIONS
Power Supply +12VDC, 1A
Infrared Output Port Six 3.5mm jacks, compatible with industry
standard IR emitters
Infrared Output
Drive
100mA maximum (per port, adjustable)
200mA maximum (high IR output port)
Infrared Frequency
Transmission Range
15kHz - 460kHz
Infrared Input Compatible with industry-standard repeaters and
receivers
Trigger Outputs Three, +12 VDC, 100mA max each
Sense Inputs Three, +3-24VDC
RS-232 Ports Two, Bi-directional RJ45 Connections
Ethernet Port 10/100Base-T, RJ45 Connection
USB Ports 1 Type B Programming
Expansion Port RS-485 / IR / Pwr, RJ45 Connection
RTI Com Port Two-way ZigBee
®
Communication Port, RJ45
Connection
Relays Three, 5 Amps @ 30 VDC Max
Mounting Wall-mount or free standing
Dimensions
(W x H x D)
10.3” (262mm) x 5.25” (134mm) x 1.5” (38mm)
Weight 2 lb. 2 oz. (970g)
Warranty One Year (Parts & Labor)
All specications subject to change without notice.
