2.4 GHz Transceiver Module

ZM-24

CONNECTION OPTIONS

Wiring between the ZM-24 and a ZigBee

enabled RTI control processor

should be cat5 cable with an RJ-45 termination (568B). Plug the cable into

the RTI COM port on the control processor and the ZM-24 up to 1000 feet

(300m) away. Additional ZM-24 modules may be used in “repeater” mode

to extend wireless coverage.

RTI COM

Repeater Repeater

ZigBee

Mesh Network
