CONNECTION OPTIONS - CONTINUED
Installations with more than one processor must have ZM-24 modules
plugged into each processor. As long as the ZM-24 modules are within
communication range of each other, a wireless mesh network will be
established. Additional ZM-24 modules may be used in “repeater” mode to
extend wireless coverage.
Two-way ZigBee
®
Enabled RTI Control Processor
ZigBee
®
Enabled RTI Control Processor
Repeater
