2.4 GHz Transceiver Module

ZM-24

PROGRAMMING

The ZM-24 connected to an RTI control processor will become the

“coordinator” module and no additional programming is required.

Additional ZM-24 modules may be used in “repeater” mode, creating a

self-healing mesh network to extend wireless coverage. ZM-24 modules

used in “repeater” mode must be programmed using a ZB-Pro Professional

2.4GHz Network Management Tool.

Programming a ZM-24 for “repeater” mode:

Plug in and attach the ZM-24 power supply.

Open the Integration Designer programming software and system le.

Open the “Communications” menu and click on “Congure ZM-24

Wireless Repeater”.

Follow the steps of the ZM-24 update wizard.

PROGRAMMING NOTES:

Please refer to the ZB-Pro operation guide for instructions on its use.

ZM-24 must be within 10 feet (3m) of a ZB-Pro for an update to occur.

The ZM-24 update process requires the programming button to be

pressed.
