17
It’s Under Control
®
CHAPTER 4 | SPECIFICATIONS
Power +9VDC to +16VDC, 60mA
RTI Com Port Two-way ZigBee
®
Communication Port, RJ45
Connection, drives up to 1000 ft (300 m) of wire
Wireless Networking IEEE 802.15.4 (ZigBee
®
Wireless Mesh
Networking)
RF Frequency Range 2.4GHz
Operating
Temperature
+32°F to +122°F (0°C to +50°C)
Operating Humidity 5% to 95% Non-condensing
Enclosure High-impact molded ABS plastic, black
Mounting Detachable bracket
Dimensions -
Antenna Flat
(W x H x D)
3.5” (89mm) x 4.0” (101mm) x 1.1” (28mm)
Dimensions -
Antenna Extend.
(W x H x D)
3.5” (89mm) x 7.25” (184mm) x 1.1” (28mm)
Weight 4 oz (113g)
Warranty One Year (Parts & Labor)
All specications subject to change without notice.
