PortaMonitor Switches and menus  Page 7-7
OPT2-KEY Input pair selection for GONIO, CORRELATOR,
2-CHA-PPM, 2-CHA+S+D-PPM and RTA mode.
NONE disables OPT2-key.
RTA-OPTION Status of RTA option: enabled or disabled
Enable RTA option if not installed:
Select RTA-OPTION field
Press NXT
Input code received from RTW
SURR-OPTION Status of surround option: enabled or disabled
Enable surround option if not installed:
Select SURR-OPTION field
Press NXT
Input code received from RTW
FACTORY Recall factory settings.
7.7.4. Submenu: GONIOMETER
AGC Operation mode for vectorscope gain:
AUTO/FIX/CALIBR.
-AUTO Operation mode for vectorscope gain switching:
FAST/SLOW
-FIX. [dB] Gain selection in AGC-FIX mode:
0, 5, 10, 15, 20, 25, 30, 35 dB
HOLD Vectorscope refresh rate:
FAST/MEDIUM/SLOW
GRID Vectorscope display mode selection:
L-R, M-S, CAL90, CAL20
COLOR GONIO Vectorscope color
-GRID Vectorscope grid color
7.7.5. Submenu: CORRELATOR
CORR Correlator display: ON/OFF
AUX-CORR Additional correlator display in MIXED mode:
ON/OFF
RESPONSE Ballistics: SLOW/FAST
COLOR + Color for positive readings
COLOR - Color for negative readings
COLOR 0 Color for display 0
COLOR GRID Correlator grid color
7.7.6. Submenu: PPM-ANALOG
SCALE Standard selection: DIN+5, DIN+10, NORDIC,
BRIIa, BRIIb, VU, ZOOM 20
OP-FIELD [dB] Operation field definition below reference (color
change). Adjustable in a range of 0 dB to 15 dB in
1 dB steps.
VU-LEAD [dB] Preset for VU lead value:
Range 0 dB to 10 dB in 1 dB steps.
Some function may only be
possible with certain versions
of hard- and software.
