7.7. Menu-description
7.7.1. Main menu
.INPUT-ROUTING submenu: input routing
.GENERAL submenu: general presets
.GONIOMETER submenu: vectorscope presets
.CORRELATOR submenu: correlator presets
.PPM-ANALOG submenu: presets for PPM-analog
.PPM-DIGITAL submenu: presets for PPM-digital
.DIG-ERRORS submenu: presets for digital error detection
.NUMERIC submenu: presets for numerical level display
.RTA submenu: presets for RTA
.SURROUND submenu: presets for surround mode
UNIT-MODE Vectorscope operation mode:GONIO-SURR/LtRt
7.7.2. Submenu: INPUT-ROUTING
INPUT-MODE Input selection: ANALOG/DIGITAL/MIXED
PPM-MODE PPM display:
OFF, 2-channel, 2-channel+sum+difference,
4-channel
PPM-INPUT PPM source status: GON/RTA-IN, INPUT 1 - 4,
Pair 1 & 2
GON/RTA-INPUT Input PAIR-x selection for vectorscope, correlator,
2-ch PPM and RTA
PAIR-1 Input routing depending on input mode
PAIR-2 Input routing depending on input mode
DISPLAY-ROUT. Routing display: ON/OFF
SURR.INPUT Input selection for surround mode: analog/digital
7.7.3. Submenu: GENERAL
SERIAL-NO Serial number display.
MENU-LOCK Enable/disable menu-lock-function.
-CODE Code selection to enable menu when menu-lock is
activated:
Code table: 1351, 4214, 2132, 6542, 4251, 6512,
4231, 4611
STANDBY Time value until dimming of backlight display after
input signal falls below an internal defined
threshold: 10 min., 60 min., OFF
BRIGHTNESS Display brightness control in steps of 10 %:
30 % ... 100 %.
OPT1-KEY A/D-SELECT allows toggling of the input domain
analog or digital for PPM, correlator and
vectorscope display.
NONE disables OPT1-key.
Some function may only be
possible with certain versions
of hard- and software.
Some function may only be
possible with certain versions
of hard- and software.
