If the power cable and the grounding cable are connected correctly.
If the power supply voltage meets the requirement.
If the configuration cable is connected correctly, the microcomputer or terminal is turned on, and the setting is
complete.
Before powering on the wireless controller, check the position of the power switch so that you may cut power supply
in time in case of accident.
4.2.2 Power-on
Turn on the power supply.
Turn the power switch of the wireless controller to the on position.
4.2.3 Verification After Power-on
After powering on the wireless controller, please check the following items:
If the ventilation system is functional.
When the wireless controller is powered on, you will hear the fan working. Put your hand near the air inlet and exhaust
vents, you will feel the air flowing.
If the indicators on the front panel of the wireless controller are in the proper state.
See LED Indicators in Chapter 1.
If the configuration terminal displays information as expected.
When the wireless controller is powered on, information on the software self-decompression will appear on the terminal
display.
4.2.4 Startup Process
When the wireless controller is started for the first time, the following information appears:
***********************************************
Boot 1.2.0-00346-g2d7093f (Build time: Mar 27 2014 - 16:04:49)
DRAM: 2 GiB
NAND: 512 MiB
Flash: 8 MiB
SETMAC: Setmac operation was performed at 2014-04-22 10:38:33 (version: 11.0)
Press Ctrl+C to enter Boot Menu
Bootloader: Done loading app on coremask: 0xffffffff
[ 0.000000] Linux version 2.6.32.13-Cavium-Octeon (ngcf@ngcf75) (gcc version 4.3.3 (Cavium Networks Version:
2_0_0 build 95) ) #1 SMP Thu May 8 04:34:42 CST 2014
[ 0.000000] CVMSEG size: 2 cache lines (256 bytes)
[ 0.000000] Cavium Inc. SDK-2.3
[ 0.000000] bootconsole [early0] enabled
[ 0.000000] CPU revision is: 000d910a (Cavium Octeon II)
[ 0.000000] Checking for the multiply/shift bug... no.
