Ruijie Reyee RG-RAP6202(G) - Horizontal Pole Mounting

Hardware Installation Guide and Reference Installation
15
3.4.3 Horizontal Pole Mounting
Note
The procedures of horizontal pole mounting are the same as those of vertical pole mounting.
Figure 3-5 Mounting the Plate on a Horizontal Pole
Figure 3-6 Horizontal Pole Mounting
