Ruijie RG-MTFi-M520 Installation And Basic Configuration Guide

Installation and Basic Configuration Guide Preparation Before Installation
1 Preparation Before Installation
1.1 Product Overview
1.1.1 Product Types
According to antenna connection, devices can be divided into following types:
Number
Physical Features
1
Single 3G/4G module, one external GPS antenna
2
Single 3G/4G module, six external antennas
3
Dual 3G/4G modules, three external antennas
4
Dual 3G/4G modules, seven external antennas
1.1.2 RG-MTFi-M520
Front Panel
Figure 1-1 Front Panel
Rear Panel
Figure 1-2 Single 3G/4G Module and One External GPS Antenna
Figure 1-3 Single 3G/4G Module and Six External Antenna

Ruijie RG-MTFi-M520 Specifications

General

Brand	Ruijie
Model	RG-MTFi-M520
Category	Network Router
Language	English
