RG-MTFI Implementation Cookbook (V1.0)
Quick Start
Install the antenna
Check RG-MTFi-
M520 after power-on
Verify the installation
End
Install the anti-theft panel
Install the power cable
Insert the SIM card
Install RG-MTFi-M520 in
a specified position using
a bracket
4.1.1 Installing the Host
Installation using a mounting bracket: Install the host in a specified position using the mounting bracket,
and fasten the host using M5 screws and nuts, as shown in the following figure.
Figure 4-1 Installation Using a Mounting Bracket
