Ruijie RG-NBS Series User Manual

1-48
Configuration Guide
eWeb Configuration (Standalone Mode)
The LLDP Info page displays information about the current device and neighbor information of each port. Click a port name to
display neighbor details of this port.
Tips:
1. LLDP can be used to display the topological connection status, for example, the numbers of switches, MED devices,
and NMS devices in the network topology.
2. LLDP can be used to detect errors, for example, display incorrect configuration information if two switches are directly
connected in the network topology.
3.7.3 RLDP
RLDP is used to detect to detect downlink loops. You can select an action among warning, block and shutdown to prevent
forwarding loops on a layer-2 network.
Figure 3-7-6 RLDP Settings
 RLDP settings
Enable RLDP, set global RLDP parameters, and click Save.
Figure 3-7-7 RLDP Management
