2.1 Configuration Preparation
2.1.1 Scenario
As shown in the figure below, you can access the eWeb management system of an access or aggregation switch via a PC
browser to manage and configure the device.
Figure 2-1-1 Network Topology
Note: The device enclosed in the red frame in the preceding figure is the accessed switch. If the switch can be pinged
successfully from the PC, you can access the eWeb management system deployed on the switch.
2.1.2 Deployment
 Configuration Environment Requirements
Client requirements:
 An administrator can log into the eWeb management system from a Web browser to manage devices. The client refers
to a PC or some other mobile endpoints such as laptops or tablets.
 Google Chrome, Firefox, IE9.0 and later versions, and some Chromium-based browsers (such as 360 Extreme Explorer)
are supported. Exceptions such as garble or format error may occur if an unsupported browser is used.
 1024 x 768 or a higher resolution is recommended. If other resolutions are used, the page fonts and formats may not be
aligned and the GUI is less artistic, or other exceptions may occur.
 The device management IP address is 10.44.77.200, and the PC can be directly connected to the device for management
and configuration.
