Configuration Guide Configuring WLAN
One-Click WLAN configuration
To perform fast configuration on an unconfigured device, one-click WLAN configuration function is developed.
This function automatically makes the following configurations on the AC or the Fat AP:
(1) Vlan Division: On an AC, VLAN 1 is the AP’s VLAN, VLAN 2 is theSTA’s VLAN; On a Fat AP, VLAN 1 is STA’s VLAN.
(2) Address Pool:
On an AC, the network segment 192.168.1.0 is AP’s address pool; The network segment 192.168.2.0 is STA’s address
pool; By default, the IP address of VLAN 1 is 192.168.1.1 and the IP address of VLAN 2 is 192.168.2.1; The default
management IP address is 88.88.88.88.
On a Fat AP, the network segment 192.168.1.0 is STA’s address pool; The IP address of BVI 1 is 192.168.1.1.
(3) WLAN Configuration: Set the WLAN name to autowifi_XXXX, the last four digits is the same as that of the device’s
MAC address; Set the WLAN-ID to 1.
(4) Security: By default, WPA2 is used for encryption; the password is autowifi.
(5) WLAN-VLAN Mapping: On an AC, map WLAN-ID 1 to VLAN 1 in the ap-group default group; On a Fat AP encapsulate
VLAN 1 on the wireless interface and set the WLAN-ID to 1.
(6) Service: Enable DHCP service.
Command Function
[no] autowifi
Use this command to enable one-click WLAN
configuration on the designated AP.
Use the no form of this command to disable one-click
WLAN configuration on the designated AP.
Configuring Received Ethernet Package Limit Per Time
You can improve the network performance by raising the received Ethernet package limit per time on an AP, at the cost of
reducing immediacy of key packages.With regard to applications which are multi-user current and immediacy sensitive,
such as electronic schoolbag, requiring only ordinary networks, you are recommended to decrease the value of received
Ethernet package limit per time to 25.
Command Function
Ruijie(config)# ap-config ap-name
Enter the configuration mode of the specified AP.
